YO18
|
Y19A
|
Y20LY
|
Y26
|
YT23
|
YT24
|
YT27
|
YT28
|
YT29A
|
YSP45
|
| Weight(kgs) |
18
|
19
|
18
|
26
|
24
|
24
|
27
|
26
|
27
|
44
|
| Length(mm) |
550
|
600
|
609
|
500 |
628
|
678
|
668
|
661
|
659
|
1420
|
| Piston stroke(mm) |
45
|
54
|
50
|
70
|
55
|
70
|
60
|
60
|
60
|
47
|
| Air consumption(L/S) |
20
|
37
|
21.6
|
47
|
80
|
66.7
|
83.3 |
82
|
88
|
113.3
|
＊ air consumption of YO18,Y19A,Y20LY,Y26 is based on 0.4Mpa working pressure
＊ air consumption of YT23,YT24,YT27,YT28,YT29A,YSP45 is based on 0.63Mpa working pressure
Pusher leg for rock drill
| |
FT140B
|
FT140BD
|
FT160A
|
FT160B
|
FT160BC
|
FT160BD
|
FT100
|
| Weight(kgs) |
16
|
14
|
17
|
16
|
17
|
15
|
12
|
| Min. Length (mm) |
1687
|
1400
|
1668
|
1428 |
1800
|
1400
|
1340
|
| Max. Length (mm) |
2937
|
2365
|
3006
|
2526
|
3165
|
2365
|
2340
|
| Feeding length(mm) |
1250
|
965
|
1338
|
1098
|
1365
|
965
|
1000 |
| Suitable machines |
YT24
|
YT24
|
YT23 YT23D
YT27 YT29A
|
YT23
YT23D
YT27
YT29A
|
YT28
|
YT28
|
Y19A Y20LY
|
